BS EN ISO · Design Stage

U-Value Calculations
Thermal performance, precisely quantified.

Thermal transmittance calculations for walls, roofs, floors, and windows to BS EN ISO 6946 and BS EN ISO 10211. A direct input into your SAP, SBEM, and Part L compliance — and a key tool for optimising your building's insulation specification.

Request U-Value Calculations What are U-values?

Request U-Value Calculations

Optimise your insulation spec — transparent pricing

First name

Last name

Email address

Phone number

Project type

Company name

Upload drawings (PDF)

✓

Thanks — we'll review your project and respond within one working day.

What are U-value calculations?

Quantifying how well your building elements resist heat loss.

A U-value measures the rate at which heat passes through a building element — a wall, roof, floor, window, or door. Expressed in watts per square metre per degree Kelvin (W/m²K), it represents the total thermal resistance of all the material layers, air gaps, and fixings that make up that element. A lower U-value means better insulation and less heat loss.

U-value calculations are a fundamental input into SAP and SBEM energy assessments, and a direct requirement of Part L of the Building Regulations. Every element of the building envelope must demonstrate that it meets the maximum U-value thresholds set by Part L — or that the overall building performance compensates for any elements that exceed them.

Beyond compliance, accurate U-value calculations are the key to optimising your insulation specification. Generic or assumed U-values can lead to over-specification — costing more in materials — or under-specification, which risks failing compliance. Bespoke calculations based on your actual build-up ensure you specify exactly what's needed, no more and no less.

Part L 2021 maximum U-values

0.13 – 0.26

W/m²K range across element types — Part L 2021, England & Wales

Walls: 0.26 W/m²K maximum. Your SAP or SBEM may require a lower value to achieve compliance depending on other elements.

Roofs: 0.16 W/m²K for pitched roofs, 0.18 W/m²K for flat roofs. Well-insulated roofs are one of the most cost-effective improvements.

Floors: 0.18 W/m²K maximum. Ground floor U-values depend on the perimeter-to-area ratio, so larger buildings perform better.

Windows & doors: 1.4 W/m²K maximum for windows, 1.4 W/m²K for doors. Frame type and glass specification both affect the result.

The calculation process

How we calculate your U-values.

We model each building element layer by layer, accounting for thermal conductivity, air gaps, fixings, and any repeating thermal bridges to produce accurate, standards-compliant results.

Build-up review

We review your construction specifications for each element — walls, roofs, floors, windows, and doors. We identify every material layer, its thickness, and its thermal conductivity.

Standards-compliant modelling

We calculate U-values to BS EN ISO 6946 for plane elements and BS EN ISO 10211 for thermal bridges. The calculation accounts for air gaps, mechanical fixings, and repeating thermal bridges that reduce the element's overall performance.

Optimisation advice

If any element exceeds the Part L threshold or your SAP/SBEM target, we advise on the most cost-effective changes — alternative insulation products, increased thickness, or different fixing methods — to bring it into compliance.

Report & SAP/SBEM integration

We deliver a detailed U-value report for each element, formatted for direct input into SAP or SBEM calculations. If we're handling both, the values flow straight into your energy assessment with no delays.

What we need from you

Information required for accurate U-value calculations.

Accurate U-value calculations depend on knowing exactly what's in each build-up. The more detail you can provide about your construction specification, the more precise the result — and the less risk of surprises at compliance stage.

Where specific product data isn't yet confirmed, we can calculate using manufacturer's declared values or conservative assumptions, and flag where the final specification will affect the result. This is common during early design stages when the spec is still being finalised.

We strongly recommend getting U-values calculated before your SAP or SBEM assessment. If the U-values don't meet the targets, it's far cheaper to adjust the specification at design stage than to remediate after construction has started.

Information required

Wall build-up Every layer from internal finish to external cladding, including insulation type, thickness, and any cavity widths.

Roof build-up Rafter or joist sizes, insulation type and thickness, ventilation gaps, and any counter-battening or boarding.

Floor build-up Slab or beam-and-block construction, insulation type and position, screed thickness, and finished floor covering.

Window & door schedule Frame material (timber, aluminium, PVCu), glazing specification (double/triple, gas fill, coatings), and spacer bar type.

Fixing details Any mechanical fixings that penetrate the insulation layer (wall ties, bracket systems, roof fixings) as these create repeating thermal bridges.

Product datasheets Manufacturer datasheets for insulation products, including declared thermal conductivity (lambda) values.

Beyond compliance

Using U-value analysis to optimise your build costs.

The right U-value isn't always the lowest one. We help you find the point where compliance meets cost-efficiency — specifying exactly what's needed without over-engineering.

Insulation selection

Choose the right product, not just the thickest

Different insulation products have different thermal conductivities. A thinner layer of high-performance insulation can achieve the same U-value as a much thicker layer of standard material — saving space and sometimes cost.

Fixing strategy

Minimise the impact of mechanical fixings

Wall ties, bracket systems, and roof fixings create thermal bridges that reduce the effective U-value of the element. We model the impact and advise on fixing patterns that minimise heat loss.

Trade-off analysis

Balance U-values across the whole envelope

Part L allows trade-offs between elements. A slightly higher wall U-value might be acceptable if the roof and floor perform better. We model the whole building to find the most cost-effective combination.

Why choose us

BS EN ISO compliant calculations

All U-values calculated to BS EN ISO 6946 and 10211, accepted by all SAP/SBEM software, building control authorities, and warranty providers across England and Wales.

Coordinated with SAP and SBEM

When we handle both U-values and energy assessments, the results feed directly into your compliance model — no re-entering data, no inconsistencies, no delays.

Optimisation, not just calculation

We don't just tell you the number. We advise on specification changes that can reduce material costs while maintaining compliance — the kind of analysis that pays for the calculation many times over.

Fast turnaround — 3–5 working days

Most U-value reports are delivered within 3–5 working days of receiving complete build-up information. Urgent turnarounds available on request.

U-value calculations near you

Local assessors for thermal performance calculations across the Midlands and South West.

U-value calculations are prepared remotely from your construction details, so location is never a barrier. Our assessors understand regional construction practices and common build-ups.

Birmingham & West Midlands

U-value calculations for new builds, extensions, and renovations across Birmingham, Solihull, Coventry, Wolverhampton, and the wider West Midlands. All element types — walls, roofs, floors, windows, and doors.

Bristol & South West

Thermal transmittance calculations across Bristol, Bath, South Gloucestershire, and the surrounding South West. Coordinated with SAP and SBEM assessments for seamless Part L compliance.

Worcestershire

Based in Worcester — U-value calculations across Malvern, Droitwich, Evesham, Bromsgrove, and Redditch. Our home county with the fastest turnaround.

Gloucestershire

U-value assessments for residential and commercial projects across Cheltenham, Gloucester, Stroud, Tewkesbury, and the Cotswolds. Bespoke build-up analysis for non-standard constructions.

Oxfordshire

Thermal performance calculations across Oxford, Banbury, Bicester, Witney, and the wider Oxfordshire area. Design stage and as-built U-values for Part L compliance.

Wider England & Wales

Our U-value calculations are accepted by all building control authorities and SAP/SBEM software across England and Wales. Contact us wherever your project is.

Looking for U-value calculations near you? Whether you need a single wall build-up assessed or a full set of element U-values for a multi-plot development — we deliver BS EN ISO compliant results with practical optimisation advice. Call 01386 365145 or email us to get started.

FAQ

Common questions about U-value calculations.

A U-value measures the rate of heat transfer through a building element, expressed in W/m²K. Lower values mean better insulation. U-values are a direct input into SAP and SBEM calculations and must meet the maximum thresholds set by Part L of the Building Regulations. Getting them right is essential for compliance — and getting them optimised can save significant material costs.

BS EN ISO 6946 covers the calculation of U-values for plane building elements — walls, roofs, and floors made up of parallel layers. BS EN ISO 10211 covers thermal bridges — junctions, fixings, and other non-uniform elements where heat flow is two- or three-dimensional. Both standards are used together to give a complete picture of an element's thermal performance.

Yes. Wall ties, bracket systems, and other mechanical fixings that penetrate the insulation layer create repeating thermal bridges, increasing the effective U-value. The impact depends on the fixing material (steel or basalt fibre), diameter, spacing, and how far they penetrate the insulation. We model these in every calculation to ensure the quoted U-value reflects real-world performance.

Yes. We calculate U-values for any construction type — timber frame, steel frame, SIPs, ICF, masonry cavity, solid wall, green roofs, inverted roofs, and bespoke hybrid systems. If you can describe the build-up, we can model it.

U-values for every element of the building envelope are a required input into both SAP (residential) and SBEM (commercial) energy calculations. The U-values directly affect the predicted heat loss, which in turn affects the energy rating, carbon emissions, and compliance outcome. Using accurate, bespoke U-values rather than generic defaults almost always improves your SAP or SBEM result.

If a specific element exceeds the Part L maximum, there are two routes. First, we can advise on specification changes to bring it into compliance — different insulation, increased thickness, or alternative fixings. Second, Part L allows trade-offs between elements, so a wall that slightly exceeds the limit may be acceptable if the roof or floor compensates. We model both options and recommend the most cost-effective approach.
